Rhombus Access Control System

Metal waterproof two-door EM card Keypad standalone access control

Metal waterproof two-door EM card Keypad standalone access control

Prezzo di listino $82.95 USD
Prezzo di listino Prezzo scontato $82.95 USD
In offerta Esaurito



Main Features:

  • Metal structure, anti-vandal, more secure , waterproof design .
  • Protective properties: IP65 fully-potted.
  • Backlight keypad.
  • Two-relay operation.
  • Pulse mode, toggle mode.
  • Up to 1,200 users (Zone 1:1,100 users & Zone 2:100 users).
  • Support 3 Modes Access: Card, PIN, Card+PIN.
  • Card Type: 125KHz EM, PIN length: 4-8 digits.
  • Operating Voltage: 12-18V AC/12-24V DC.
  • Support done bell connection (Zone 2).
  • Very low power consumption ( ≤35mA), long service life and stable performance.
  • Application for High-Security Places: warehouses, banks, prisons, etc.
  • High Speed Search: filled with 1,200 users, the search time < 0.1 seconds.
  • With anti-demolition alarm function, anti-static interference 15KV.
  • Product Certification: CE

Specifications:

  • Operating Voltage: 12-18V AC/12-24V DC
  • Card Type: 125KHz EM
  • Adjustable Door Relay Time: 1-99s
  • Static Current: ≤35mA
  • Card Read Rang: 3-6cm
  • Reader Induction Time: ≤0.1s
  • Operating Temperature: -40oC~60oC
  • Operating Humidity: 0-95%
  • Lock Output Load: 1A
  • Alarm Output Load: 3A
  • Antistatic: 15KV
  • Environment: Conform to IP65
  • Wiring Length: 90-100cm
  • Dimension: L128mm×W82mm×H28m


Connection Diagram:


Packing List:

  • 1 × Digital Keypad
  • 1 × User Manual
  • 1 × Screw Driver
  • 4 × Rubber Bungs
  • 4 × Self Tapping Screws
