Industrial HF 13.56MHz RFID reader and writer/ Modbus workstation reader/POE carrier body reader
Industrial HF 13.56MHz RFID reader and writer/ Modbus workstation reader/POE carrier body reader
通常価格
$162.95 USD
通常価格
セール価格
$162.95 USD
単価
あたり
受取状況を読み込めませんでした
- Multi protocol read and write M1, 15693, Ntag21x tags
- MODBUS protocol directly connected to PLC, supporting simple and composite instructions
- Modbus RTU, serial protocol (RS232/485)
- Modbus TCP, TCP/IP protocol (RJ45)
- Support active uploading of any data within the configuration card
- Support initializing and writing label data
- 304 stainless steel body, TCP network port version supports POE power supply
- Built in red and green LED indicator lights and buzzer
- The baud rate for data transmission can be freely set
- Supports cascading reading of RS485 readers and writers, with free address configuration
- Supports TCP readers and writers to freely configure IP addresses, enabling multi device networking
- Support readers to set internal upload keys
- Optional data reporting and deduplication function
- Provide convenient C # testing application software and instruction set development documentation
- Convenient secondary development
- Product models: XZ803, YZ903
- Output power:<400mW
- Card reading distance: 0-90mm
- Communication protocols: serial port, TCP/IP, Modbus
- Communication interface: RS485, RS232, TCP
- Working frequency: 13.56MHz
- Working voltage: 7.5-36V
- Working mode: automatic, master-slave command
- Work protocol: ISO15693/ISO14443A
- Protection level: IP67
- Work tips: Red and green LEDs, buzzer
- Working temperature: -20 ℃~70 ℃
- Working humidity: -10% RH~95% RH (non condensing)
- Material: 304 stainless steel
- Product size: M30x97mm
