Wiring-free Wireless 3A Battery 1K User 125KHz EM/ID Standalone Access Control

Name: Wiring-free Wireless 3A Battery 1K User 125KHz EM/ID Standalone Access Control
Brand: Rhombus Access Control System
Price: 46.95 USD
Availability: InStock

$46.95 USD

Распродажа Продано

Colour Black+Black Black+Grey Black+Golden Remote control

Варианты товара

Количество

Product advantages

The control system with no wire connection is adopted for the set of the entrance guard controller and the door button, which avoids complex sequences of wiring and punching.

Installation precautions

The wireless door guard device and the wireless door switch cannot be installed on metal door or metal surface wall, otherwise, it will affect the performance of the product.

The overall features of the wireless entrance guard:

1. You can set 1000 cards, with 1000 standard user capacity.

2. The ways of opening the door: induction card, password, induction card and password, induction card or password.

3. The wireless entrance guard device is powered by battery without wiring connection. The operation and usage is simple and clear.lt is flexible to add or remove a card. The card can be deleted offline.

4. The code - drawing is used for switch coding, which is flexible and simple and can effectively prevent the interference of adjacent entrance guard device.

The technical parameters of the wireless entrance guard device:

The wireless entrance guard device is powered by four AAA dry batteries (1.5V).
Standby current: 28mA Action current: 38mA
Storage capacity:1000 standard users (ID card) output time: 1s to 10s (adjustable)
User card type: 125KHZ or EM EM compatible card
The password of opening the door: one public password
Read card distance: 10 to 70 (mm) Wireless transmitting distance: greater than or equal to 8 m
Battery life: over 6 months (less than 100 times per day)
Wireless transmission frequency: 315 MHZ working environment temperature: -10 °C 70°C
Material: Plastic
External size: 139 x 75 x 25 ( mm )

Wireless exit switch parameters:

Powered by: 1 x 12V 23A Battery (included)
Operating Frequency: 315MHz±2MHz
Material: Plastic
Size:83x40x15(mm)

Wireless exit switch parameters:

Powered by: 1 x 12V 23A Battery (included)
Operating Frequency: 315MHz±2MHz
Material: Plastic
Size:83x40x15(mm)

Power parameters

Input Voltage:AC100-240V 50/60Hz
Output voltage:DC12V/5A
Wireless Receive Control Output
Wireless reception doorbell
Size:145x58*32(mm)

The operation guide of the wireless entrance guard device

	Continuous key operation
operation name	System password	function	operation		quit	operation results		remark
Change system password	#12345	1	88888#88888#		*	The system password is 88888		The system password is five-digit number.
Change the door password	#12345	2	2580(example) e)		*	The door password is 2580		The door password is four-digit number.
Set the opening mode	#12345	3	00 is for password; 01 is just for cards; 02 is for cards or password; 03 is for cards and password.		*	The open mode is the selected mode.		The factory default is 02 mode.
Add a card (card number) Add cards	#12345	4	0# card number##		*	The card number is added .All the ID cards which are		The card number is the number that is sprayed on the ID card, the last eight-digit number
Add cards (continuous read cards)	#12345	4	1# read card #		*	All the ID cards which are continuously read are added		Many cards can be read continuously.	In common use
Remove a card (card number)	#12345	6	0# card number#		*	The card number is removed.		The card number is the number that is sprayed on the ID card,the last eight-digit number
Remove cards (continuous read cards)	#12345	6	1# read card #		*	All the ID cards which are continuously read are removed.		Many cards can be read continuously.	In common use
Remove all cards	#12345	8	88# (long whistle)		*	All the user cards are removed.		All user cards can be success fully removed after the buzzer gives a long sound
Change door-opening time	#12345	0	02 (double-digit seconds)		*	The door-opening time is change to 2 seconds.		From 01 to 10 seconds	in common use
System initialization	Open the back cover and remove the battery. Turn the band switch to “ RESEET"			Install the batteries, the buzzer rings five times and the indicator light flashes five times			^ Remove the batteries and turn the band switch to “NORMAL”	The system password is restored to 12345. All other data should not be removed.
Remark: The factory password defaults to 12345.After you press #12345, you can hear three consecutive beeps, then the system password has been changed. The system initialization is required to restore.
